Products Description
A red dot sight is a non-magnifying reflector optical sight that projects a luminous red (or green) aiming point onto the lens for rapid targeting. Its greatest advantage is allowing the shooter to keep both eyes open with unlimited eye relief and no parallax, enabling lightning-fast target acquisition while maintaining full situational awareness.
Applications
It is primarily used for close-quarters rapid-fire shooting, tracking moving targets, tactical CQB (close-quarters battle) operations, and hunting, making it an essential standard accessory for modern firearms and tactical setups.
Functions
parameter | Specification |
Selectable Reticle | Yes |
Shake Awake Technology | Yes |
Memory | Yes |
Green Laser Pointer | Yes |
IR Laser Pointer | Yes |
Manual Brightness | Yes |
Optical Data
parameter | Specification | |
Light Source | LED | |
Wavelength | 650nm | |
Reticle | Dot & Circle | |
Magnification | 1x | |
Parallax | No | |
Unlimited Eye Relief | Yes | |
Multi-Coatings | Yes | |
Green Laser Output Power | < 5mW | |
Green Laser Class | Class 3R | |
IR Pointer Output Power | < 0.7mW | |
IR Pointer Class | Class 1 | |
Green Laser Wavelength | 520nm | |
IR Laser Wavelength | 850nm | |
Brightness Setting | 8 Daylight & 4 Night Vision | |
Electronic Data
parameter | Specification |
Battery | CR123A |
Red Dot Battery Life | Setting 6 - 300,000 Hours |
Green Laser Battery Life | 12 Hours |
IR Laser Battery Life IR | 50 Hours |
Brightness Setting | 8 Daylight & 4 Night Vision |
Removable Battery | Yes |
Battery Location | Side Tray |
Mechanical Data
parameter | Specification |
Housing Material | 6061 Aluminum |
Surface Finish | Hard Anodized |
Housing Color | Black |
Adjustment Per Click | 0.5 MOA |
W&E Travel Range | ±50 MOA |
Storage Temperature | -40°C ~ 70°C |
Working Temperature | -30°C ~ 60°C |
Submersion | IPX8 |
Vibration | 1000G |
Physical Data
parameter | Specification |
Window Size | 1.26" × 0.98" |
Body Dimensions | 3.03" × 2" × 2.68" |
Body Weight | 10.6 oz |
Central Mount Height | 1.63" |
Fitment
parameter | Specification |
Direct Mount | Picatinny |
