Products Description
This digital night vision device features a 1920×1080 CMOS sensor, 940nm infrared illumination, AMOLED display, and 3W IR LED for clear night observation. It supports video recording, playback, multi-language menu, and up to 128GB storage, making it ideal for outdoor observation, security, and wildlife monitoring.
1. USE HANDHELD OR HEAD MOUNTED: The Red is supplied with an adjustable head strap as standard, making it easy to go handsfree. Using third party mounts (not supplied), you can also mount the Red to a helmet, tactical helmet or bump helmet using the GoPro-compatible connection point on the top of the device.
2. HD FOOTAGE WITH AUDIO: The Red boasts a Full High Definition (FHD) infrared camera sensor: 1920*1080p resolution, producing excellent quality video footage. video footage also includes audio recording. To record footage, a Micro SD card is required (not included).
3. HD FOOTAGE WITH AUDIO: The Red boasts a Full High Definition (FHD) infrared camera sensor: 1920*1080p resolution, producing excellent quality video footage. Thanks to an integrated microphone, video footage also includes audio recording.
Parameter Description：
| Category | Project | Parameter Description |
| Optical Performance | Magnification power | 1~3.5× |
| Digital Zoom | Max 3.5× | |
| Angle of View | 22° | |
| Objective Aperture | 15mm | |
| Exit Pupil Distance | 40mm | |
| F# for Objective lens | 1.3 | |
| Video Output | Display | 240×536 resolution AMOLED |
| OSD menu | Supported | |
| Imager | Sensor | CMOS High-sensitivity Sensor |
| Sensor Size | 1/2.8" | |
| Resolution | 1920×1080 | |
| IR LED | Infrared Light | 3W IR LED with 940nm |
| Micro SD Card | Storage | Supports SDHC 4GB–128GB TF Card |
| Hardware Buttons | Power/Mode | Power on/off or MODE |
| Snapshot | Snap | |
| Zoom | ZOOM | |
| IR Control | IR switch Up/Down | |
| Operation | Video | Record MOV file in SD storage |
| Playback | Playback media file from SD card | |
| Power | External Power | Type-C 5V/2A |
| Battery | 2× CR123A (4V–6V) | |
| Battery Life | About 6 hours (IR off) | |
| Warning | Low battery warning | |
| System | Modes | Video / Playback / Menu |
| Functions | Video record / playback / ｄｅｌｅｔｅ | |
| IR Levels | 5 levels (USB power), 3 levels (battery) | |
| Auto Power Off | Off / 3min / 5min / 10min | |
| Language | English / French / Spanish / Portuguese / Deutsch / 9 languages | |
| Light Frequency | 50/60Hz | |
| Display Brightness | OLED 4 levels | |
| Format | Supported | |
| Version | — | |
| Size | Dimensions | 140mm × 75mm × 58mm |
| Weight | 350g (without battery) | |
| Package | Included Items | USB cable / AV cable / Micro SD card / Bag / Manual |
